Spesification Sheet NNP74430DL
| Type of Luminaire | Downlight |
|---|---|
| I Series | |
| 20,5W Type | |
| Set Model No. | NNP74430DL |
| Type of Light Source | LED |
|---|---|
| Power Input | 20,5W |
| System Lumen Output | 2110 |
| System Efficacy | 102.9lm/W |
| Power Voltage | AC 220-240V |
| Power Factor | 0.9 |
| Lifetime | 40.000h |
| CCT | 5000K |
| CRI | 80 |
| Input Frequency | 50/60Hz |
| Glare Cut | 15° |
| Beam Angle | 95deg. |
| IP Rating | 20 |
| Ambient Temperature | 5°C until 35°C |
| Cut Out Size | ∅150 |
| Dimensions | 170mm * 88mm |
| Body | Aluminum Die Cast |
| Reflector | Anodized Aluminum Specular |
| Frame | Painted Cool White |
| Country of Origin | Indonesia |
| Brand | Panasonic |
